Zone 4P

168,500 (198,830 Inc. GST @ 18%)

No Cost EMI starts at
16,569/month

EMI Options →
GST invoice available

4 zone audio controller with DSP, amplification and WebApp

DATA SHEET USER GUIDE
Features
  • Full suite of audio controls for up to 4 zones
  • Fully flexible signal routing
  • 4 channels of integrated amplification
  • WebApp interface for easy system configuration and everyday control
  • 2 mic, 4 stereo line and 2 HDMI inputs
  • Fully programmable presets and timed events
  • Very competitive pricing

Not in Stock, Pre-order Only

Description

Bars/Restaurants & Cafes

Retail

Wedding Venues

Hotels

Education Facilities

Houses of Worship

Corporate Offices

Museums

Fitness Studios

Residential

Flexibility and ease of use are core values of Optimal Audio and the Zone series has been created to give easy access to everyday controls. Zone 4P has integrated amplification making installation straightforward and cost-effective.

Zone 4P allows the user to independently allocate sources across four configurable zones, which could be anything from the bar, back of house or lobby to restaurant, kitchen or shop floor.

Zone 4P is the heart of any sound system, handling audio signal management for four zones and includes four integrated channels of amplifier. Each zone can be configured to do precisely what is required using the intuitive WebApp. It features 4 line and 2 mic inputs plus 2 HDMI inputs for TV and video sound.

The integrated amplifiers in Zone 4P eliminates the need for separate amplifiers for most small to medium applications.

Zone 4P has been designed to work seamlessly with other products in the Optimal Audio range and when coupled with our ZonePad series provides a simple, intuitive and cost-effective audio system with superb sound quality.



Specifications

TYPE4 zone audio processor with DSP, amplification and loudspeaker presets
MIC INPUTS2 with 48V phantom power, +12dB to +55dB gain
MIC INPUT PROCESSINGFixed hi-pass filter @160Hz; sweepable mid-band 200Hz-5kHz, +/-12dB; HF shelf @12kHz
LINE INPUTS4 stereo with +26dB gain trim. SPDIF option on input 1
HDMI INPUTS2 withARC
LINE OUTPUTS4
ZONEPAD SOCKETS4
AMPLIFIER CHANNELS4
AMPLIFIER POWER100W at 4Ω or 8Ω
PAGING INPUTS (CAT 5)2
LAN ETHERNET100MbpsYes
ALARM OVERRIDEYes
DIMENSIONS(W) 480mm x (H) 88mm x (D) 400mm
(W) 18.90” x (H) 3.46” x (D) 15.75”
WEIGHT9.75kg (21.5lbs)

Drawings

Zone 4P
