Van Damme Ecoflex Install Grade LSZH Twin Axial Speaker Cable

Call for price

Van Damme Ecoflex Install Grade Twin Axial Speaker Cable LSZH is a Low Smoke Zero Halogen insulated and jacketed cable range. it is specifically designed for installation in public buildings and other areas where LSZH materials are specified such as new-build housing and marine installations. From 2 x 0.75 mm2 for 100V line to 2 x 4.00 mm2 for low impedance systems most speaker applications are well catered for.

SKU: Install Grade 2 Core Speaker Cable Category: Tags: , , ,

Description

APPLICATIONS

  • Speaker installations in public buildings such as Government Premises, Schools and Colleges
  • Marine Installations

Application Notes

  • Fully tested and compliant with the following IEC standards: IEC 60332.1 Fire retardancy of a single cable; IEC 60332.3.24 Fire retardancy of bunched cables; IEC 60754.1 Amount of Halogen Gas Emissions; IEC 60754.2 Degree of acidity of released gases; IEC 61034.2 Measurement of smoke density
  • Ultra-pure oxygen-free copper for outstanding sonic integrity

General Specification

Conductor: Bare ultra-pure linear crystal oxygen-free copper

Insulation: SHF1 LSZH thermoplastic polymer

Jacket: SHF1 LSZH thermoplastic polymer Anthracite Grey RAL 7016

Working Voltage: 300/500 V

Bend Radius: 10 x overall diameter

Operating temperature: -35 to +70 ⁰C

Part Nos. & Description

Part NumberDescriptionMax. Reel Length
278-575-080Van Damme Ecoflex Install Grade 2 x 0.75 mm² twin-axial500m
278-515-080Van Damme Ecoflex Install Grade 2 x 1.50 mm² twin-axial500m
278-525-080Van Damme Ecoflex Install Grade 2 x 2.50 mm² twin-axial500m
278-545-080Van Damme Ecoflex Install Grade 2 x 4.00 mm² twin-axial500m
278-524-080Van Damme Ecoflex Install Grade 2 x 4.00 mm² twin-axial500m
